Rent Black Magic Hdmi to SDI Cross Converter in Mumbai
from ₹1000/day
1 rental offer in Mumbai
The Blackmagic Micro Converter HDMI to SDI 3G is the world's smallest broadcast-grade video converter, designed to bridge the gap between consumer HDMI gear and professional SDI infrastructure.
Rental offers in Mumbai
Highlights
Signal Conversion
Converts HDMI consumer camera or laptop signals to professional 3G-SDI for broadcast use.
SDI Re-clocking
Features built-in SDI re-clocking on the 3G-SDI output to allow for long cable runs without signal degradation.
Multi-rate Support
Automatically detects and switches between SD and HD video formats up to 1080p60.
USB Power
Powered via a standard USB-C connection, allowing it to be powered by monitors, laptops, or portable battery packs.
Compact Design
Rugged metal chassis small enough to be used in tight spaces or mounted directly on camera rigs.
Specifications
| SDI Video Outputs | 2 x SD, HD or 3G-SDI (automatically matches HDMI input) |
| HDMI Video Inputs | 1 x HDMI Type A |
| SDI Rates | 270Mb, 1.5G, 3G |
| Video Standards | 525i59.94 NTSC, 625i50 PAL, 720p50/59.94/60, 1080p23.98/24/25/29.97/30/47.95/48/50/59.94/60 |
| Power Consumption | 2.0 Watts |
| Operational Voltage Range | 4.4V to 5.25V DC |
Frequently asked questions
Does the Blackmagic HDMI to SDI converter support 4K?
No, the 3G model supports resolutions up to 1080p at 60fps. For 4K workflows, you would require the 12G-SDI version of the converter.
How is the Blackmagic Micro Converter powered?
It is powered via a USB-C port. You can plug it into a wall outlet using a 5V adapter, or power it directly from a camera's USB port or a power bank.
Can I use this to connect my Sony A7III to a broadcast switcher?
Yes, this is the primary use case. It converts the Sony's HDMI output to SDI, which is the standard input for professional switchers like the ATEM Television Studio.
